    Floor Tile LED DisplayP2.976P3.91P4.81

    Ask Lasest Price
    Brand Name : CRTOP
    Model Number : P4.81mm
    Certification : CE/FCC/ETL
    Price :
    Payment Terms :
    Supply Ability :
    Delivery Time :
    • Product Details
    • Company Profile

    Floor Tile LED DisplayP2.976P3.91P4.81

    IP20 Indoor LED Display Screen Rental Intelligent Sensing Design


    source manufacturere P4.81mm stage floor PC mask led display used in stage activity etc


    Brick /floor Stage led display

    1. The bottom case, face shield, power cord and signal line of the LED floor tile screen module are specially designed and equipped with waterproof and moisture-proof materials. They are made of raw materials with low moisture absorption coefficient. The front and rear of the body can reach the waterproof level of IP 65 .

    2. The LED intelligent interactive floor tile screen mask is made of imported PC material, which has high wear resistance and flexibility, as well as good high and low temperature resistance. And it is designed according to the mechanical principle, with good anti-skid and load-bearing functions.


    Pitch:.

    Indoor P2.97 P3.91 P4.81

    Module size: 250x250mm

    Outdoor P3.91 P4.81

    Box size: 500*500 500*1000


    P2.976P3.91P 4.81 outdoor floor tile screen parameter table
    serial numbernameprojectTechnical indicators
    1LED tubeLamp bead shapeSMD1 921
    2pixel compositionArrangementvertical
    3Pixel tube spacing4.81 mm
    4pixel composition1R1G1B
    5base color compositionRed, green, blue three primary colors
    6physical density43264 points/㎡
    7

    module

    Box size

    Module size250×250X15 height mm (length X width X thickness)
    8Module resolution52 width × 52 height (dots)
    9Box sizeIron box foot installation 1000x500mm
    10runaway point≤4/100000
    11Unit module seamThe size of the gap between the unit plates is the same, and ≤1 mm
    12best distance7-20m
    13perspectiveHorizontal 120°, Vertical 120°
    14Surface roughnessMaximum error ≤ 1 mm
    15Screen surface ink colorconsistent ink color
    16uniformityModule brightness is uniform
    17Use environmentambient temperature-20°~50°
    18Relative humidity25°~95°
    19powered supplyInput voltage (AC)220V, ±10%
    20Earth leakage current< 3Ma
    twenty oneinput frequency50/60HZ
    twenty twoaverage power3 5 0W/㎡
    twenty threepeak power800W/㎡
    25way to controlSync with computer VGA (monitor sync)
    26Control SystemDVI graphics card + full color control card + optical fiber transmission
    27InputComputer and other peripherals, VGA, HDMI, DVI, etc.
    29refresh rate1920hz
    30Grayscale/ColorLevel 8192
    31Full screen brightness35 00cd/㎡
    32service lifeMore than 100,000 hours
    33Display contentVideo DVD, VCD, TV, images, text, animation, and others.
    34Continuous trouble-free working time≥10000 hours
    35interfaceStandard Ethermer network interface (Gigabit)
    36Communication medium, control distanceMultimode fiber < 500m, single mode fiber transmission < 30km, Category 5 cable < 100m
    37protection technologyWaterproof, moisture-proof, dust-proof, anti-corrosion, anti-static, lightning-proof, with over-current/short-circuit, over-voltage, under-voltage protection functions at the same time
