    hot sale source manufacturer HD IP65 outdoor P2.5mm led display

    Ask Lasest Price
    Brand Name : CRTOP
    Model Number : P2.5mm
    Certification : CE/FCC/ETL
    Price :
    Payment Terms :
    Supply Ability :
    Delivery Time :
    • Product Details
    • Company Profile

    hot sale source manufacturer HD IP65 outdoor P2.5mm led display

    Outdoor LED display product features and parameters:

    1,Using high-grade chip packaged LED lights, low gray and high brightness, fully guarantees the service life and display quality of the display screen, and adopts a low-turnover voltage constant-current driver IC. The advantage of this driver chip is that it can reduce the voltage falling on the output terminals of the IC. Reduce the power consumption, improve the power loss of the IC, and then achieve the effect of energy saving. The AC fan with large exhaust air volume is adopted, and the components are reasonably arranged to improve the uniformity of heat dissipation. According to the principle that the Vf of the R lamp is low, the 3.8V and 2.8V power supplies are used to supply power separately, reducing the excess voltage drop by 30%. The system sets the automatic brightness adjustment function, which can automatically adjust the brightness of the screen according to the ambient brightness, dynamic energy saving

    2,Support 4.2V~5V and 2.8V/3.8V power supply mode, the power supply selection is more flexible, and there is no risk of burning the module with mixed power supply

    3,a variety of module sizes , flexible collocation, more considerate upgrades , strict material selection

    4,Standard 1920Hz refresh rate, the video picture is more delicate and smooth; 9000:1 high contrast ratio, improve the contrast between light and dark, enhance the picture details, restore the true color

    5,Diversely used in commercial real estate, shopping malls, large squares, outdoor advertising screens, traffic screens and other fields


    Point spacing: P2.5, P3, P3.07, P3.91, P4, P5, P5.33, P6, P8, P10

    Module size: 192x192mm 160x160mm 320x160mm 250x250mm 256x128mm

    Box size: 768x768mm 960*960*120mm 500x1000mm 1024x768mm


    projectparameterRemark

    BASIC PARAMETER

    pixel pitch2.5mm _
    pixel structure1R1G1B
    pixel density160000 /m 2
    Module resolution64(W)* 64 (H)
    Module size160mm * 160mm _
    Box size640*640mm

    OPTIC PARAMETER

    Single point luminance, chromaticity correctionhave
    white balance brightness≥ 5 0 00cd/㎡
    color temperature3200K—9300K adjustable
    Horizontal viewing angle≥ 120°
    vertical viewing angle≥ 120°
    Visible distance≥8 meters
    Brightness uniformity≥97%
    Contrast≥ 5 000:1

    Proccessing Performance

    Signal processing bits16 bits*3
    grayscale16Bit
    control distanceGigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers
    drive modeHigh gray-scale constant current source driver IC
    frame rate≥ 60HZ
    refresh rate≥ 1920 Hz
    way to controlSynchronize
    Brightness adjustment range0 to 100 stepless adjustment

    Operation performance

    Continuous working time≥72 hours
    Typical life50,000 hours
    Protection classFront IP65, back IP43
    range of working temperature-20℃ to 50℃
    Operating humidity range10%- 80% RH non-condensing
    Storage temperature range-20 ℃ to 60 ℃

    Electric parameter

    Operating VoltageDC 5V
    Power RequirementsAC:220×(1±10%)V, 50×(1±5%)Hz
    Maximum power consumption8 5 0W/ ㎡
    Average power consumption350W/ ㎡
