    High Refresh Radiator Fan Outdoor LED Advertising Screen For Large Squares P8

    Ask Lasest Price
    Brand Name : CRTOP
    Model Number : P8mm
    Certification : CE/FCC/ETL
    • Product Details
    • Company Profile

    High Refresh Radiator Fan Outdoor LED Advertising Screen For Large Squares P8

    High Refresh Radiator Fan Outdoor LED Advertising Screen For Large Squares


    P8 radiator fan Outdoor Led Screen for shopping center for large squares


    1. Using high-grade chip packaged LED lights, low gray and high brightness, fully guarantees the service life and display quality of the display screen.

    2. The advantage of this driver chip is that it can reduce the voltage falling on the output terminals of the IC. Reduce the power consumption, improve the power loss of the IC, and then achieve the effect of energy saving.

    3. a variety of module sizes , flexible collocation, more considerate upgrades , strict material selection


    Quick Details:
    ● Integrated power design saves time
    ● Double quick lock design
    ● More durable, single operation
    ● Quick installation and maintenance
    ● Modular design of power control
    ● No wire is needed to connect
    ● The cabinet is light and thin
    ● Unique module design, no left and right
    ● Private design of PCB
    ● Same HUB could useing all kinds of pixel
    ● Wide viewing angle, no reflection


    projectparameterRemark

    BASIC

    PARAMETER

    pixel pitch8mm
    pixel structure1R1G1B
    pixel density15625/m 2
    Module resolution32(W)*16(H)
    Module size256mm*128mm
    Box size1024mm*768mm

    OPTIC

    PARAMETER

    Single point luminance, chromaticity correctionhave
    white balance brightness≥ 55 00cd/㎡
    color temperature3200K—9300K adjustable
    Horizontal viewing angle≥ 120°
    vertical viewing angle≥ 120°
    Visible distance≥16 meters
    Brightness uniformity≥97%
    Contrast≥3000:1

    Proccessing Performance

    Signal processing bits16 bits*3
    grayscale16Bit
    control distanceGigabit Ethernet cable: 100 meters, Optical fiber: 10 kilometers
    drive modeHigh gray-scale constant current source driver IC
    frame rate≥ 60HZ
    refresh rate≥ 1920 Hz
    way to controlSynchronize
    Brightness adjustment range0 to 100 stepless adjustment

    Operation performance

    Continuous working time≥72 hours
    Typical life50,000 hours
    Protection classFront IP65, back IP43
    range of working temperature-20℃ to 50℃
    Operating humidity range10 %- 80% RH non-condensing
    Storage temperature range-20 ℃ to 60 ℃

    Electric

    parameter

    Operating VoltageDC 5V
    Power RequirementsAC: 220×(1±10%)V, 50×(1±5%)Hz
    Maximum power consumption850W/ ㎡
    Average power consumption360W/ ㎡

    FAQ


    Q: What is the brightness, viewing angle and wavelength of the LED?

    A: Luminous Intensity is equal to the amount of luminous flux emitted into a very small solid angle at a defined angular orientation from the light source. The measurement for luminous intensity is the candela. Symbol is Iv.

    Viewing Angle is the total cone angle in degrees encompassing the central, high luminous intensity portion of the LED beam from the on-axis peak to the off-axis point where the LED intensity is 50% of the on-axis intensity. This off-axis point is known as theta one-half ( 1/2). Two times 1/2 is the LEDs' full viewing angle; however, light is visible beyond the1/2 point.

    Wavelength is the distance between two points of corresponding phase and is equal to waveform velocity divided by frequency. It defines what color human eyes could recognize

    Q: What is dominant wavelength? Please specify the ranges of wavelength in red, green and blue color respectively.
    A: Dominant wavelength is defined as the best range of wavelength showing the most natural color recognized by human eyes. Researches indicate that fixed colors with wavelength of 620-630nm (red), 520-530nm (green) and 460-470nm (blue), in fact mixed in a particular proportion, can get the pure white. That is, in display field, people use luminous materials with above wavelength to make "compounded" white more natural.In order to get a good balance white led display, we specify the led colors with wavelength within 4nm for each color
    Q: Which chip vendors are you buying from?
    A: It depends on the Customer's requirement. We can purchase from Japan, Korea, Europe, USA. We are using chips mainly from Taiwan
    Q: What is the chip size you're using for outdoor display? How about indoor display?
    A: For outdoor display, we're using 12mil chip for red, 14mil for both green and blue. Regarding indoor display, 9mil for red, 12mil for green and blue are currently adopted
    Q: How much will the brightness of LED drop down after 1000hrs?
    A: Based on the result of aging test, the brightness decay of green LED is around 5%-8%, while blue is around 10%-14% and red is around 5%-8%
